Vdi Medical
1 / 5
| Technical Specifications | |
|---|---|
| Display | |
| Display Type | 7 inch high resolution LCD display |
| Sweep Speed | 25mm/sec |
| Information | HR, Lead/Pads, On/Off Alarm, SpO2, AED Functions and Prompts, Alarm Selection and Limits, Delivered Energy. |
| Defibrillator Features | |
| Waveform | Biphasic |
| Charge Time | Less than 7 seconds with a new fully charged battery. |
| Energy Display | Monitor display indicates both selected and delivered energy. |
| Charge Prompt Type | Voice and visual prompts. |
| Impedance Range | 0-250 ohms. |
| ECG Monitoring | |
| Patient Connection | 5-lead ECG cable, or 3-lead ECG cable, paddles. |
| Lead Selection | I, II, III, AVR, AVL, AVF, V. |
| Heart Rate | 20-300BPM with user-selectable alarms. |
| SpO2 Module | |
| Measurement Range | 30~100%, ± 2% between 80%~90% |
| Battery & Power | |
| Type | Rechargeable, Ni-MH battery, 12V. |
| Operating Time | 60 discharges at max energy or 3 hours continuous ECG monitoring. |
| AED & Manual Mode | |
| AED Function | Auto analyze and charge X3 with programmable auto energy level selection. |
| Energy Selection (Manual) | 2, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, 360 joules. |
| Synchronized Mode | Synchronizes defibrillator pulse to patient's R-wave. |
The group provides a wide range of medical solutions including Medical imaging, In-vitro diagnostics, Life support, Patient monitoring, and Infant care equipment. With a commitment to innovation, at least 6% of gross output is invested in R&D annually, bringing advanced international-level products to over 100 countries.
Professionalism is at our core, with a high percentage of technical engineers possessing over 15 years of experience in the medical field. We strive to provide a "One-stop-shop" experience, competitive pricing, and excellent quality controlled by strict QC steps.
