Basic Info.
Case Management:
AED storage software makes the selected data file a case record and stores cases in the database ACCESS. Case management supports importing and deleting data that can respond to the ECG waveform of the data file by selecting cases.
Memory Playback:
The interface displays status information recorded during AED operation, including type, event time, description, and waves. Event types include: Power On, Self Test, Analysis, Charge, Discharge, CPR start/stop.
ECG & Print:
Waveform gain set to 5mm/mv, 10mm/mv, 20mm/mv; Waveform speed 12.5 mm/s, 25 mm/s, 50 mm/s. Can preview and print basic information.
What waveform does this AED use?
This device uses the Biphasic Truncated Exponential waveform, which is the standard for modern effective defibrillation.
Can it be used on both adults and children?
Yes, the device features specific modes for both Adult and Child patients to ensure appropriate energy delivery.
How many events can the device store?
The unit can store up to 1800 ECG events, which can be reviewed later using the management software.
What is the maximum energy output?
The device provides a maximum energy output of 200 Joules.
Is there a warranty provided?
Yes, the product comes with a standard 1-year warranty for quality assurance.
How is data transferred from the AED?
Data transmission is handled via an Infrared interface for easy case management and playback.
